FEATURES
- Multi Function Power Supply
- Multichannel Pipette Compatible
- UV Transparent Electrophoresis Tank
SPECIFICATIONS
| ■Electrophoresis Cell | |||
| Overall dimensions | 183mm(W)×56mm(H)×164mm(L) | ||
| Material | UV transparent plastic (254nm→50%、312nm→80%) |
||
| Solution volume | Approx. 270-320ml（buffer solution only） | ||
| Multi-sample | Multichannel-pipette compatible |
||
 |
|||
| ■Safety Lid | |||
| Overall dimensions | 197mm(W)×38mm(H)×169mm(L) | ||
|
|||
| ■Power Supply | |||
| Overall dimensions | 75mm(W)×62mm(H)×170mm(L) | ||
| Weight | 410ｇ | ||
| Input voltage | AC100〜240V、AC50/60Hz | ||
| Output voltage |
|
||
| Timer | Timer operation 0 – 99 min. and continuous mode Pause function supported |
||
| Safety switch | Micro-switches in the power supply without safety lid, no output of Power | ||
| Memory function | Automatic memory (the last used V & T) | ||
|
|||
| ■Gel Tray | |||
| Gel Tray – S | 130mm(W)×13mm(H)×59.5mm(L) | ||
| Gel Tray – L | 130mm(W)×13mm(H)×122mm(L) | ||
| Quantity | Gel Tray – S : 2 , Gel Tray – L : 1 | ||
|
|||
| ■Comb | |||
| Multiple number of wells | 13 or 26 wells (13wells: 9mm spacing 26wells: 4.5mm spacing) |
||
| Quantity | 4 | ||
|
|||
| ■Gelmaker Stand | |||
| Overall dimensions | 149mm(W)×20mm(H)×125mm(L) | ||
